SPECIFICATIONS
Module Type JKSM3-CFCA-350 JKSM3-CFCA-355 JKSM3-CFCA-360 JKSM3-CFCA-365 JKSM3-CFCA-370
STC NOCT STC NOCT STC NOCT STC NOCT STC NOCT
Maximum Power (Pmax) 350Wp 260Wp 355Wp 264Wp 360Wp 267Wp 365Wp 271Wp 370Wp 275Wp
Maximum Power Voltage (Vmp) 36.85V 34.37V 36.95V 34.54V 37.04V 34.66V 37.14V 34.83V 37.23V 34.99V
Maximum Power Current (Imp) 9.50A 7.56A 9.61A 7.63A 9.72A 7.71A 9.83A 7.78A 9.94A 7.85A
Open-circuit Voltage (Voc) 44.20V 41.63V 44.30V 41.72V 44.40V 41.82V 44.50V 41.91V 44.60V 42.01V
Short-circuit Current (Isc) 9.95A 8.04A 10.03A 8.10A 10.11A 8.17A 10.19A 8.23A 10.27A 8.29A
Module Efficiency STC (%) 19.53% 19.80% 20.08% 20.36% 20.64%
Operating Temperature(℃) -40℃~+85℃
Maximum system voltage 1000VDC (IEC)
Maximum series fuse rating 20A
Power tolerance 0~+3%
Temperature coefficients of Pmax -0.36%/℃
Temperature coefficients of Voc -0.29%/℃
Temperature coefficients of Isc 0.048%/℃
Nominal operating cell temperature (NOCT) 45±2℃
* STC: Irradiance 1000W/m 2 Cell Temperature 25°C AM=1.5
NOCT: Irradiance 800W/m Ambient Temperature 20°C AM=1.5 Wind Speed 1m/s
2
* Power measurement tolerance: ± 3%
The company reserves the final right for explanation on any of the information presented hereby. JKSM3-CFCA-350-370-A1-EN-for CEC Listing
